Description
ENGINE: Left & Right
- Description: Rolls Royce Deutschland BR710A2-20
- Engine Total Time: New
- Engine Cycles: New
- Thrust: 14,750 lbs. each
- TBO: On Condition
- Program Coverage: TBD
View Full Spec
APU
- Description: Honeywell RE220 (GX)
- Program Coverage: TBD
AVIONICS:
The Global 6000 is equipped with an integrated four tube 15.1” LCD Collins Pro-Line Fusion avionics suite. A general summary of this aircraft’s Collin’s Pro-Line Fusion avionics suite is as follows:
Dual Primary Flight Displays (PFD)
Dual Multi-Function Displays (MFD) for Integrated Navigation, Weather & Traffic Information, Enhanced Maps
Dual Engine Indication and Crew Alerting System Displays (EICAS)
Electronic Flight Instrument System (EFIS)
Dual VOR/ILS/MKR NAV Receivers
Dual DME-4000 Transceivers
Dual ADF Receivers
Triple Air Data Computers (ADC)
Dual SELCAL Decoder
Cockpit Voice Recorder (120 min)
Flight Data Recorder (25 hr)
Quick Access Recorder
Maintenance Diagnostic System (MDS)
HUD
EVS
Triple Flight Management System
Dual Channel Autopilot System
Triple Inertial Reference Systems (IRS)
Triple Integrated Flight Information Systems (IFIS)
Dual GPS Receivers/Sensors
Digital Color Weather Radar System
Triple VHF Comm (8.33 kHz Spacing)
Dual Digital HF Comm
VHF Datalink with Iridium Interface
Dual Enhanced Mode S Transponder
TCAS II with Change 7
Directional TCAS Antenna
Traffic Avoidance Warning System (TAWS)
Artex 406 Emergency Locator Transmitter (ELT)
2nd Radio Altimeter
Lightning Detection System
ADDITIONAL EQUIPMENT
Rockwell Collins Cabin Entertainment System
Airshow ASXi Cabin Display
ICS Dual Channel Iridium Telephone with two cordless 1.9 GHz cabin handset on crew rest handset and one cockpit handset
Auto throttle
Rosen Cockpit Sun visor System
LED Lighting Throughout
One 3.5 KVA 115VAC 60Hz Power Converter
Fifteen (15) Electrical Outlets (230V 50Hz)
Cabin and Lavatory Call Switch With Cockpit Chime
2nd Refuel Defuel Panel (Entrance)
First Aid Kit
Crash Axe
Two (2) Flashlights
Soundproofing Package
Global Office
10/100 Base T Ethernet LAN
RJ-45 LAN Interface at each seat
Wireless LAN
Inkjet Printer/Fax/Scanner
Portable Multimedia Input Port
Enviroclean System
Inmarsat Satcom Level D Certified
Two (2) Inmarsat Aero H+ Channels
One (1) cockpit data channel
One (1) Iridium based communication channel
Dual Channel high speed data
Co-Pilot Electronic Flight Bag (EFB) w/expansion module
Track and Swivel Jumpseat
Two (2) 24.” Flat Screen LCD Monitors
Three (3) 10.4” LCD Monitors
Three (3) Dual Disk CD/DVD/MP3 players
Wireless Remote Control
Audio Speakers (10)
Stereo Headsets (18)
CD-ROM version of IPC, MM, Wiring Diagrams and Chapter 5
One (1) Therapeutic Oxygen Outlet located in Cabin
Jeppesen Under-floor Manual Storage
Aft Equipment Bay Storage Box
Locking Fuel Caps
Avionics Bay Light
Maintenance Ladder
Cockpit Printer
Noise Cancelling Headsets (Crew, Qty 3)
EXTERIOR:
Overall Matterhorn white with grey accent striping
INTERIOR:
13 passenger configuration features
four (4) place club in the forward cabin and an executive workstation facing a 4-seat conference table grouping in the mid compartment with dual three (3) place divans in the aft cabin.
The forward seats in the aft divans are not certified for taxi, take-off, and landing.
Gallery Items
Espresso Maker
Gasper Cooled Food Storage Area
High Temp Oven
Soda Can Storage Compartment
Mini Liquor Storage
Paper Towel Holder
Two (2) Pull Out Work Surfaces
Divided Ice Drawer with overboard drain
Trash Compartment
Microwave Oven
Stainless Steel Sink
Backlit Crystal Showcase Area
Galley Touch Screen Control Monitor
Miscellaneous Storage Drawers
Insta Hot Water
Specifications subject to verification, upon inspection. Price and times subject to change, without notice Aircraft offered subject to prior sale or withdrawal from the market.
